Aluminium 4 Seats ADC 48V 3.7KW Electric Patrol Car / Electric Cruise Vehicle

Aluminium 4 Seats ADC 48V 3.7KW Electric Patrol Car / Electric Cruise Vehicle
Aluminium 4 Seats ADC 48V 3.7KW Electric Patrol Car / Electric Cruise Vehicle

Large Image :  Aluminium 4 Seats ADC 48V 3.7KW Electric Patrol Car / Electric Cruise Vehicle

Product Details:

Place of Origin: China
Brand Name: EXCAR
Certification: CE
Model Number: A1S4

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit
Price: Negotiate
Packaging Details: LCL shipment Packing:roof move-off packing, steel frame , carton paper cover.
Delivery Time: 7 days after received your deposit
Payment Terms: D/A, D/P, Western Union, MoneyGram, L/C, T/T
Supply Ability: 300 units per month
Detailed Product Description
Transaxle: Italy Graziano Alex Warranty: 1 Year
Production Time: 7-15 Days After Deposit Paid Body Color: White Or Based On Panton Number
Brand: EXCAR Motor: ADC 48V 3.7KW
Chassis: Aluminium Chassis F/R Track: 860 / 970 MM
Max.forward Speed: 24 KM/H
High Light:

electric patrol vehicle

,

security golf carts

Aluminium Excar 4 Seats ADC 48V 3.7KW Electric Patrol Car Electric cruise car





Feature of Product:



Features
※ Italy Graziano Transaxle
※ Unique E-KEY
※ Electromagnetic Brake Makes Driving More Safty
※ Special Design LED Headlight
※ Advanced Disc Brake Technology
※ Three-point Seat Belts
※ Rear View Mirror And Driver/Passenger Side Mirrors
※ Automotive Safty Glass Windshield
※ Deep Cup Holders
※ Comfortable,Contoured Seats
※ 100% waterproof accelerator





Performance



Item Description
system DC system AC system
Passenger Capacity 4 4
Climbing capacity(full load) 30% 35%
Max. forward speed 23km/h 45km/h
Endurance mileage 70-90km 80-90km
Charging time 8-10 hours 8-10 hours
Max.loading weight 360kgs 360kgs
Min.turning radius 3.9m 3.9m
Max. movement after brake at speed of 20km/h ≤4m ≤4m

1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;

2) Range will vary depending on temperature, grade, payload and driving style.



Dimensions



Item Description
Overall dimensions (L x W x H) 3200x1200x1900mm
Ground clearance 114mm
Wheelbase 2490mm
Front wheel tread (mm) 860mm
Rear wheel tread (mm) 970mm



Body and Frame



Item Description
Frame & Chassis Aluminum alloy beam, bended
Body PP engineering plastic front and rear body cover, injected
Roof Glass fiber reinforced plastic
Windshield Organic glass (PMMA),one-piece or two pieces
Roof supports Imbedding black coating steel tube in the plastic support
Cushion Reborn sponge with artificial leather and plastic bottom cover
Backrest Reborn sponge with artificial leather and plastic cover
Armrest Plastic
Floor mat Anti-skidding rubber
Rear basket Plastic
Golf bag holder Plastic support with nylon strap
Dashboard Black plasticmaterial, battery power indicator, ignition key on it
Beverage holders 4 pcs cups holders, 2 pcs for each side
Side trim Plastic, black
Score card holder On the steering wheel



Electric System



Item Description
Lights

48V, LED headlight (includes turning light and position light),

LED taillights (includes brake lights and turning light),

Horn Electric horn, 48V
Reverse buzzer Electric, 48V
Combination switch Control the lights and horn
Digital Meter (optional) Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock



Packing & Shipping



Model Dimension(mm) 20” container 40” container
M1S2+2FF With roof & windshield Without roof & windshield With roof & windshield Without roof & windshield With roof & windshield Without roof & windshield
3200*1200*1800 3200*1200*1400 4 units 8units 8units 16units
