Product Details:
Payment & Shipping Terms:
|
Body Color: | White Or Customized | Roof Color: | White,black Or Beige |
---|---|---|---|
Seat Color: | White,black Or Beige | Warranty: | 1 Year |
Motor: | USA ADC Brand | Controller: | USA Curties Controller |
Battery: | 48V Trojan Battery 6*8V | Transaxle: | Italy Graziano Axle |
Range: | 60-80 KM | ||
High Light: | classic golf carts,electric vintage car |
AE Approved White 6 seats Electric Classic Car 48V Trojan Battery Electric Vintage Cars
Key Components
Item | Description | |
System | DC system | AC system |
Controller | Curtis controller 1266A-5301, 350A, imported from USA directly | Curtis controller 1234E-5321, 350A, imported from USA directly |
Motor |
ADC brand Separately excited DC motor 48V 3.7kw |
ADC brand Separately excited AC motor 48V 5kw |
Battery | Trojan battery, T875,8V*6pcs, imported from USA directly | Trojan battery, T875,8V*6pcs, imported from USA directly |
Transaxle |
Italian GRAZIANO axle with gear ration 1:12 |
Italian GRAZIANO axle with gear ration 1:16 |
Charger |
High Frequency onboard charger 48V/17A regulator |
High Frequency onboard charger 48V/17A regulator |
Performance
Item | Description | |
system | DC system | AC system |
Passenger Capacity | 8 | 8 |
Climbing capacity(full load) | 20% | 25% |
Max. forward speed | 23km/h | 45km/h |
Endurance mileage | 50-70km | 60-80km |
Charging time | 8-10 hours | 8-10 hours |
Max.loading weight | 510kgs | 510kgs |
Min.turning radius | 5.1m | 5.1m |
Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
Item | Description |
Overall dimensions (L x W x H) | 4292x1219x1828mm |
Ground clearance | 114mm |
Wheelbase | 3300mm |
Front wheel tread (mm) | 860mm |
Rear wheel tread (mm) | 970mm |
Body and Frame
Item | Description |
Frame & Chassis | Steel alloy framework |
Body | PP engineering plastic front and rear body cover, injected |
Roof | Glass fiber reinforced plastic |
Windshield | Organic glass (PMMA),one-piece or two pieces |
Roof supports | Imbedding black coating steel tube in the plastic support |
Cushion | Reborn sponge with artificial leather and plastic bottom cover |
Backrest | Reborn sponge with artificial leather and plastic cover |
Armrest | Plastic |
Floor mat | Anti-skidding rubber |
Rear basket | Plastic |
Golf bag holder | Plastic support with nylon strap |
Dashboard | Black plasticmaterial, battery power indicator, ignition key on it |
Beverage holders | 4 pcs cups holders, 2 pcs for each side |
Side trim | Plastic, black |
Score card holder | On the steering wheel |
Electric System
Item | Description |
Lights |
48V, LED headlight (includes turning light and position light), LED taillights (includes brake lights and turning light), |
Horn | Electric horn, 48V |
Reverse buzzer | Electric, 48V |
Combination switch | Control the lights and horn |
Digital Meter (optional) | Including kilometer indicator, speed indicator, overload indicator, parking brake indicator, clock |
Steering &suspersion
Item | Description |
Steering System |
Self-adjusting rack and pinion steering system, with automatic compensation function |
Brake System | Rear wheel mechanical brake |
Accelerator | Holzer type, stepless speed change |
Front suspension | Mcphersonindependent spring suspension |
Rear suspension | Coil spring hydraulic shock absorber |
Driving model | Rear axle two stage deceleration, motor direct driving |
Wheel &Tyre | Aluminum wheel &USA Carlisle 18*8.5-8 6 layers |
Product Display
FAQ
6.What's your payment term?
T /T 30% deposit and balance paid before shipment
Service
1.For all your inquires about us or our products, we will reply you in detail within 24 hours.
2. We offer OEM services. Can print your own logo on product ,can customize the electrical golf cart body colour and other things.
3.Our director who developed the golf cart and he is the Doctor for engineering,and he has more than 10 years experience with the cart,so any carts problem you can contact him.He can speak fluent English to solve any your problem.
