Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: CK2+2
Payment & Shipping Terms
Minimum Order Quantity: 1 Unit
Price: Negotiate
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: 1000 units per month
Model NO.: |
CK2+2 |
Power Fuel: |
Electric |
Power: |
5kw |
Maximum Speed: |
45km/h |
Voltage Of Battery: |
48V |
Gradeability: |
20-30% |
Suitable For: |
Golf Cousre, Hotels,Hilly Landscapes, Tourist Area, Villa |
Model NO.: |
CK2+2 |
Power Fuel: |
Electric |
Power: |
5kw |
Maximum Speed: |
45km/h |
Voltage Of Battery: |
48V |
Gradeability: |
20-30% |
Suitable For: |
Golf Cousre, Hotels,Hilly Landscapes, Tourist Area, Villa |
Product Description :
| CONFIGURATION | |
| MOTOR: | EXCAR 48V 5KW(AC) |
| CONTROLLER: | EXCAR 48V/350A AC CONTROLLER |
| BATTERIES: | 48V |
| CHARGER: | 48V 17A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | SPECIAL REAR AXLE FOR ELECTRIC VEHICLE |
| BRAKE SYSTEM: | REAR SELF-ADJUSTING DRUM BRAKE |
| STEERING STSREM: | DUAL SELF-ADJUSTING RACK & PINION |
| F/R SUSPENSION: | MACPHERSON INDEPENDENT SPRING |
Dimensions:
| DIMENSION | 2350*1130*1850MM |
| NET WEIGHT | 470KG |
| PAY LOAD | 250KG |
| F/R TRACK | 860/970MM |
| WHEEL BASE | 1670MM |
| GROUND CLEARANCE | 114MM |
| MIN.TURNING RADIUS | 4.1M |
Option Accessories
To increase the sales value of our golf cart, we also provide many optional accessories
| Item | Option description | Item | Option description |
| 1 | E-key | 11 | 2-point seatbelt |
| 2 | Hinged windshield | 12 | Battery water refill system |
| 3 | Laminated windshield with wiper | 13 | Digital meter |
| 4 | Steel brush guard | 14 | EM brake |
| 5 | Front steel basket | 15 | Four wheel disc brake |
| 6 | Inner rear view mirror | 16 | Carlisle 205/50-10tyre with10inch wheel |
| 7 | Side rear view mirror | 17 | Ice box |
| 8 | Enclosure | 18 | Sand bottle |
| 9 | Sunshine cover | 19 | Sand rake |
| 10 | Golf bag cover | 20 | Ball washer |
Packing & Shipping
Excar golf cart will be packed in steel crate
| Model | Dimension(mm) | 20” container | 40” container | |||
| A1S2 | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield |
| 2641*1219*1727 | 2641*1219*1250 | 4 units | 8units | 10units | 20units | |
a) LCL shipment Packing:
roof move-off packing, steel frame , cartoon paper cover.
b)FCL shipment Packing:
packed by plastic foam & plastic film
