Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: G1S2
Payment & Shipping Terms
Minimum Order Quantity: 1pc
Price: Negotiate
Packaging Details: 20' container or 40' container
Delivery Time: 7-15 working days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 3000pcs per year
Body Color: |
Blue,White, Black, Customized |
Roof Color: |
Blue,White, Black, Customized |
Seat Color: |
Beige Or Black, White |
Lead Time: |
7-15 Days After Deposit Paid |
Warranty: |
2 Years Since The Day To Ship Out |
Logo: |
Excar Silver Logo Or Gold Logo Or Customized |
Color: |
White, Blue |
Range: |
60-80KM |
Battery: |
72V Trojan Battery |
Controller: |
Curtis Controller |
Body Color: |
Blue,White, Black, Customized |
Roof Color: |
Blue,White, Black, Customized |
Seat Color: |
Beige Or Black, White |
Lead Time: |
7-15 Days After Deposit Paid |
Warranty: |
2 Years Since The Day To Ship Out |
Logo: |
Excar Silver Logo Or Gold Logo Or Customized |
Color: |
White, Blue |
Range: |
60-80KM |
Battery: |
72V Trojan Battery |
Controller: |
Curtis Controller |
Tourist Use Electric Utility Carts , Advanced Battery Powered Sightseeing Bus
Specification
|
SPECIFICATIONS OF 8 Seater Electric Sightseeing Car LS6082K
|
||
|
Key Components |
Controller | Curtis AC 72V 350A |
| Motor | KDS 72V 7.5KW | |
| Battery | Trojan T-105 12*6V | |
|
Performance and Dimensions |
Passenger Capacity | 2 |
| Range (Loaded) * | 60-80kms | |
| Max.speed | 40km/h | |
| Min. Turning Radius | 5.7m | |
| Max. Gradeability | 25% | |
| Max. Loading Weight | 640kgs | |
| Net Weight | 1120kgs | |
| Overall Dimensions | 5300X1500X2000mm | |
|
Body and Frame |
||
| Frame (Chassis) | Welded steel framework, with anti-rust treatment of sand blasting and painting | |
| Body and Roof | FRP body, seat pot and roof | |
| Windshield | Laminated glass, with wiper | |
| Roof supports | Aluminum | |
| Seat | High back seat with head rest for driver, bench seat for passengers | |
| Floor | Anti-slip rubber floor mat | |
| Dashboard | FRP, with F/R Switch, Emergency Stop Switch, Digital Meter | |
| Side trim | Aluminum alloy | |
| Sider mirror | 2pcs, foldable | |
|
Electric System |
||
| Lighting system and horn | 2 headlights, 2 front turn signals, 2 brake light, 2 rear turn signal, 1 reverse light, 1 rear fog light, with voltage reducer (converting from 48V to 12V), electric horn. | |
| Digital Meter | With battery power meter, amperemeter, voltmeter, speedometer, odometer, time, F/R indicator, turn signal indicator | |
| Audio system | CD player and radio, with 4 speakers | |
| Combination switch | Light switch, wiper switch, horn switch | |
| Backup Buzzer | 12V | |
| Charger | Smart charger, input 110V-240V~50Hz-60Hz, output 48V, 25A | |
|
Steering, Brake, Transmission and Suspension |
||
| Steering System | EPS (Electric power steering) system | |
| Brake system | Vacuum booster hydraulic brake | |
| Accelerator | Stepless speed change | |
| Driving mode | Rear axle two stage deceleration, motor direct driving | |
| Rear axle | Heavy duty axle with differential gear | |
| Suspension system | Mcpherson independent spring suspension | |
| Wheel & Tyre | 175/60R14 Tyre | |
Color Option
※ Body Color:White,Black,Beige,Champagene,Dark Green,Red,Metallic Red,Purple,Yellow,Green,Pink,Blue,Dark Blue or made on Panton number
※ Seat Color:Black, White or Beige
※ Roof Color:Blue,White or Beige
Product Image
Our Certificate
FAQ
1, what's your warranty time?
Usually for 1 year
2, What's the production time?
Normally for 7-15 working days
3, What's your payment term?
T/T 30% deposit and balance paid before shipment
4, Can we also purchase the parts
Yes,if you do maintainess service,you can also buy parts from us
5, How do you provide after-sales once customer bought the cart from us?
Once you purchase the cart from us,then i will provide you manual to learn it and tell you how to fix it.
6.What is your MOQ?
You can order just 1 unit .
7,Can we put the Logo we designed on the cart?
Yes, you can put your own Logo on the cart.
8,What's your payment term?
T/T 30% deposit and balance paid before shipment
9,How do you make our business long-term and good relationship?
1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
