Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S2
Payment & Shipping Terms
Minimum Order Quantity: 1pc
Price: Negotiate
Packaging Details: 20' container or 40' container
Delivery Time: 7-15 working days
Payment Terms: T/T, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 3000pcs per year
Body Color: |
Blue Or Do On Pantone Number |
Roof Color: |
White,black And White |
Seat: |
2 Person |
Motor: |
ADC Motor |
Controller: |
Curties Controller 48V 275A |
Batteries: |
Trojan Battery 48V |
Transaxle: |
Italy Graziano Axle |
Max.Forward Speed: |
25km/h |
Body Color: |
Blue Or Do On Pantone Number |
Roof Color: |
White,black And White |
Seat: |
2 Person |
Motor: |
ADC Motor |
Controller: |
Curties Controller 48V 275A |
Batteries: |
Trojan Battery 48V |
Transaxle: |
Italy Graziano Axle |
Max.Forward Speed: |
25km/h |
3.7KW Motor 2 Seater Electric Hungting Carts Trojan Battery Green Color Electric Hungting Cart
We focus on golf cart industry in recent years.And we use best parts to ensure our quality.
Although our monthly output is high, small order is still accepted for this model of golfcart, to facilitate our customers of different kinds.
This type of golf cart is becoming more and more popular, and we're selling very well over the country.
Feather of golf cart:
※ Advanced Disc Brake Technology
※ Global Special LED Headlight
※ Italy Graziano Transaxle
※ Curtis Controller 48V 275A
※ Eletromagnetic Brake Makes Driving More Safty
※ 100% Waterproof accelerator
Specification
| Configuration | |||
| Battery | 6*8V 275AH Trojan T-875 | ||
| Power of Motor | 48V 3700W | ||
| Controller | American Curtis Electronics Controller | ||
| Accelerator | Adjustable Inductive Accelerator Continuously Variable Speed System | ||
| Transaxle | Italy Graziano axle | ||
| Charger | Intelligent Onbaord Charger | ||
| Chassis configuration | |||
| Front-Suspension | Independent Spring Front Suspension | ||
| Rear-Suspension | Spring Hydraulic Shock Absorbers | ||
| Steering | Dual Self Adjusting "Rack&Pinion" Steetring | ||
| Brakes | Rear Wheel Mechanical Drum Brake and Regeneration Brake | ||
| Performance | |||
| Max Speed | 25 km/h | Chassis | Aluminum |
| Max Travel Distance | 80-100km | Wheelbase | 1670mm |
| Slope Climbing Capacity | 30% | Front Wheel Tread | 860mm |
| Brake Range | ≤3m | Rear Wheel Tread | 970mm |
| Max Noise | <50dB | Tires | 205/50-10 |
| Carrying Capacity | 600KG | Dimension | 2700*1200*1900mm |
| Turning Radius | 2900mm | Passengers | 2 Person |
| Net Weight | 430kg | Ground Clearance | 124mm |
Option Accessories
To increase the sales value of our golf cart, we also provide many optional accessories.
| Item | Option description | Item | Option description |
| 1 | E-key | 11 | 2-point seatbelt |
| 2 | Hinged windshield | 12 | Battery water refill system |
| 3 | Laminated windshield with wiper | 13 | Digital meter |
| 4 | Steel brush guard | 14 | EM brake |
| 5 | Front steel basket | 15 | Four wheel disc brake |
| 6 | Inner rear view mirror | 16 | Carlisle 205/50-10 tyre with10inch wheel |
| 7 | Side rear view mirror | 17 | Ice box |
| 8 | Enclosure | 18 | Sand bottle |
| 9 | Sunshine cover | 19 | Sand rake |
| 10 | Golf bag cover | 20 | Ball washer |
Packing & Shipping
Excar golf cart will be packed in steel crate
| Model | Dimension(mm) | 20” container | 40” container | |||
| A1S2 | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield | With roof & windshield | Without roof & windshield |
| 2641*1219*1727 | 2641*1219*1250 | 4 units | 8units | 10units | 20units | |
| FAQ | |||||
| 1.Can you customize the cart according to our special request? | |||||
| Yes,we can customize the cart according to your request unless some complex parts we hard to make. | |||||
| 2.What is your MOQ? | |||||
| You can order just 1 unit .But if your order is big, we will provide you with a discount. | |||||
| 3.Can we put the Logo we designed on the cart? | |||||
| Yes, you can put your own Logo on the cart. | |||||
| 4.What is your lead time for production? | |||||
| The typical lead time of our cart is 15 days. | |||||
| 5.What kind of warranty Excar provides? | |||||
| Non-artificial damaged products,shifting for a year or one year repair. |
|
||||
| Application | |||
| Our excar golf cart can be used in many places,like Golf Course,Hotel,Campus,Park,Airport,Tourist Resorts,Museum,Mountain Area,Wedding Place and so on. |
