Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE, ISO9001
Model Number: A1S6+2
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD 4595/ Units
Packaging Details: LCL shipment packaging /CKD
Delivery Time: 25 days
Payment Terms: L/C, T/T
Supply Ability: 400units/ month
Seats: |
8 |
Battery: |
Trojan Battery |
Color: |
Customized |
Voltage: |
48V |
Dimension: |
4300/1200/1900mm |
Chassis: |
Aluminum Chassis |
Netweight: |
600KG |
Pay Load: |
500KG |
Climbing Capacity: |
20% |
Max.Forward Speed: |
24km/h |
F/R TRACK: |
860/970mm |
Ground Clearance: |
114mm |
Min.Turning Radius: |
5.1M |
Wheelbase: |
3300mm |
Range: |
50-70km |
Seats: |
8 |
Battery: |
Trojan Battery |
Color: |
Customized |
Voltage: |
48V |
Dimension: |
4300/1200/1900mm |
Chassis: |
Aluminum Chassis |
Netweight: |
600KG |
Pay Load: |
500KG |
Climbing Capacity: |
20% |
Max.Forward Speed: |
24km/h |
F/R TRACK: |
860/970mm |
Ground Clearance: |
114mm |
Min.Turning Radius: |
5.1M |
Wheelbase: |
3300mm |
Range: |
50-70km |
Product Description :
| CONFIGURATION | |
| MOTOR: | EXCAR 48V 3.7KW(AC) |
| CONTROLLER: | EXCAR 48V/350A AC CONTROLLER |
| BATTERIES: | 48V |
| CHARGER: | 48V 17A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | SPECIAL REAR AXLE FOR ELECTRIC VEHICLE |
| BRAKE SYSTEM: | REAR SELF-ADJUSTING DRUM BRAKE |
| STEERING STSREM: | DUAL SELF-ADJUSTING RACK & PINION |
| F/R SUSPENSION: | MCPHERSON INDEPENDENT SPRING |
Performance
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 8 | 8 |
| Climbing capacity(full load) | 20% | 25% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 50-70km | 60-80km |
| Charging time | 8-10 hours | 8-10 hours |
| Max. loading weight | 510kgs | 510kgs |
| Min. turning radius | 5.1m | 5.1m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
| Item | Description |
| Overall dimensions (L x W x H) | 4292x1219x1828mm |
| Ground clearance | 114mm |
| Wheelbase | 3300mm |
| Front wheel tread (mm) | 860mm |
| Rear wheel tread (mm) | 970mm |
