Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S4+2
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model::: |
A1S4+2/FF |
Color::: |
Customized |
Battery::: |
Trojan Battery |
Netweight::: |
560KG |
F/R TRACK::: |
860/970MM |
Range::: |
60-80KM |
Seats::: |
4+2 |
Dimension::: |
3500/1200/1900mm |
Voltage::: |
48V |
Climbing Capacity:: |
30% |
Min.Turning Radius::: |
3.9M |
Max.Forward Speed::: |
24KM/H |
Model::: |
A1S4+2/FF |
Color::: |
Customized |
Battery::: |
Trojan Battery |
Netweight::: |
560KG |
F/R TRACK::: |
860/970MM |
Range::: |
60-80KM |
Seats::: |
4+2 |
Dimension::: |
3500/1200/1900mm |
Voltage::: |
48V |
Climbing Capacity:: |
30% |
Min.Turning Radius::: |
3.9M |
Max.Forward Speed::: |
24KM/H |
Product Description :
| CONFIGURATION | |
| MOTOR: | EXCAR 48V 3.7KW(AC) |
| CONTROLLER: | EXCAR 48V/350A AC CONTROLLER |
| BATTERIES: | 48V |
| CHARGER: | 48V 17A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | SPECIAL REAR AXLE FOR ELECTRIC VEHICLE |
| BRAKE SYSTEM: | REAR SELF-ADJUSTING DRUM BRAKE |
| STEERING STSREM: | DUAL SELF-ADJUSTING RACK & PINION |
| F/R SUSPENSION: | MCPHERSON INDEPENDENT SPRING |
Performance
| Item | Description | |
| System | DC system | AC system |
| Passenger Capacity | 6 | 6 |
| Climbing capacity(full load) | 30% | 35% |
| Max.Forward speed | 23km/h | 45km/h |
| Endurance mileage | 50-70km | 60-80km |
| Charging time | 8-10 hours | 8-10 hours |
| Max.Loading weight | 360kgs | 360kgs |
| Min.Turning radius | 3.9m | 3.9m |
| Max.Movement after brake at speed of 20km/h | ≤4m | ≤4m |
* 1) based on the test conditions:20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
| Item | Description |
| Overall dimensions (L x W x H) | 3454x1219x1828mm |
| Ground clearance | 114mm |
| Wheelbase | 2490mm |
| Front wheel tread (mm) | 860mm |
| Rear wheel tread (mm) | 970mm |
