Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S6
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model: |
A1S6 |
Seats:: |
6 |
Battery Voltage:: |
48V Trojan Battery |
Color:: |
Customized |
Cargo Size:: |
800*1100*280mm |
Netweight:: |
590KG |
Climbing Capacity:: |
20% |
F/R TRACK:: |
860/970mm |
Min.Turning Radius:: |
5.1M |
Range:: |
50-70km |
Model: |
A1S6 |
Seats:: |
6 |
Battery Voltage:: |
48V Trojan Battery |
Color:: |
Customized |
Cargo Size:: |
800*1100*280mm |
Netweight:: |
590KG |
Climbing Capacity:: |
20% |
F/R TRACK:: |
860/970mm |
Min.Turning Radius:: |
5.1M |
Range:: |
50-70km |
Dimensions
| Item | Description |
| Overall dimensions (L x W x H) | 4000x1200x1800mm |
| Ground clearance | 114mm |
| Wheelbase | 3300mm |
| Front wheel tread (mm) | 860mm |
| Rear wheel tread (mm) | 970mm |
| Pay Load | 510KG |
| Climbing Capacity | 20% |
| Max. Forward Speed | 24KM/H |
| Range | 50-70KM |
| Tyre | 18/8.5-8 |
Performance
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 6 | 6 |
| Climbing capacity(full load) | 20% | 25% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 50-70km | 60-80km |
| Charging time | 8-10 hours | 8-10 hours |
| Max. loading weight | 510kgs | 510kgs |
| Min. turning radius | 5.1m | 5.1m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
Color options
| Body colour | White | Grey | Sky blue |
| Dark blue | Red | Wine red | |
| Green | Dark green | Yellow | |
| Purple | Champagne | Black | |
| These are the popular colours, but your customized color is available,just provide the right Panton No. color | |||
| Seat & Roof colour | Black | Beige | White |
