Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1H4
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model NO.: |
A1H4 |
Maximum Speed: |
>30 Km/h |
Power Fuel: |
Electric |
Gradeability: |
20-30% |
Voltage Of Battery: |
48V |
Specification: |
4000*1200*1800MM |
Certification: |
CE, ISO |
Model NO.: |
A1H4 |
Maximum Speed: |
>30 Km/h |
Power Fuel: |
Electric |
Gradeability: |
20-30% |
Voltage Of Battery: |
48V |
Specification: |
4000*1200*1800MM |
Certification: |
CE, ISO |
Product Description:
|
Article
|
Value
|
|
Model Number
|
A1H4
|
|
Dimension
|
4000*1200*1800MM
|
|
Wheel Base
|
3300MM
|
|
Land clearance
|
114MM
|
|
Turning Radius Min.
|
5.1M
|
|
Net weight
|
590KG
|
|
Payment Load
|
510kg
|
|
Climbing ability (fully loaded)
|
20%
|
|
Loom
|
Steel frame
|
|
Maximum forwarding rate
|
24 KM/H
|
|
Range
|
50-70KM
|
|
Load size and rise angle
|
1200*1700*250MM; 25 degrees
|
|
Tire
|
18/8.5-8
|
Configuration
| Item | Description | |
| System | DC system | AC system |
| Controller | Curtis controller 1266A-5201, 275A, imported from USA directly | Curtis controller 1234E-5221, 275A, imported from USA directly |
| Motor | ADC brand Separately excited DC motor 48V 3.7kw |
ADC brand Separately excited AC motor 48V 5kw |
| Battery | Trojan battery, T875,8V*6pcs, imported from USA directly | Trojan battery, T875,8V*6pcs, imported from USA directly |
| Transaxle | Italian GRAZIANO axle with gear ration 1:12 |
Italian GRAZIANO axle with gear ration 1:16 |
| Charger | High Frequency onboard charger 48V/17A regulator |
High Frequency onboard charger 48V/17A regulator |
