Dongguan Excar Electric Vehicle Co., Ltd salescn@excar.com.cn 86--13546943585
Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: A1S4
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Negotiable
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: Negotiable
Model NO.: |
A1S4 |
Power Fuel: |
Electric |
Gradeability: |
20-30% |
Certification: |
CE, ISO |
Controller: |
48V/350A Curtis Conroller |
Transaxle: |
Italy Graziano Axle |
Chassis: |
Aluminum Chassis |
Specification: |
48V Electric Golf Cart |
Power: |
3.7kw |
Maximum Speed: |
20-30 Km/h |
Suitable For: |
Golf Course/Villa/Tourist Area/Holiday Village |
Voltage Of Battery: |
48V |
Motor: |
48V 3.7kw ADC Motor |
Battery: |
USA Trojan T-875 6*8V |
Tyre: |
Carlisle 18X8.5-8 6 Layers Tyre |
Model NO.: |
A1S4 |
Power Fuel: |
Electric |
Gradeability: |
20-30% |
Certification: |
CE, ISO |
Controller: |
48V/350A Curtis Conroller |
Transaxle: |
Italy Graziano Axle |
Chassis: |
Aluminum Chassis |
Specification: |
48V Electric Golf Cart |
Power: |
3.7kw |
Maximum Speed: |
20-30 Km/h |
Suitable For: |
Golf Course/Villa/Tourist Area/Holiday Village |
Voltage Of Battery: |
48V |
Motor: |
48V 3.7kw ADC Motor |
Battery: |
USA Trojan T-875 6*8V |
Tyre: |
Carlisle 18X8.5-8 6 Layers Tyre |
Key Components
| Item | Description | |
| System | DC system | AC system |
| Controller | Curtis controller 1266A-5201, 275A, imported from USA directly | Curtis controller 1234E-5221, 275A, imported from USA directly |
| Motor | ADC brand Separately excited DC motor 48V 3.7kw |
ADC brand Separately excited AC motor 48V 3kw |
| Battery | Trojan battery, T875,8V*6pcs, imported from USA directly | Trojan battery, T875,8V*6pcs, imported from USA directly |
| Transaxle | Italian GRAZIANO axle with gear ration 1:12 |
Italian GRAZIANO axle with gear ration 1:16 |
| Charger | High Frequency onboard charger 48V/17A regulator |
High Frequency onboard charger 48V/17A regulator |
Performance
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 4 | 4 |
| Climbing capacity(full load) | 30% | 35% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 70-90km | 80-90km |
| Charging time | 8-10 hours | 8-10 hours |
| Max. loading weight | 360kgs | 360kgs |
| Min. turning radius | 3.9m | 3.9m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
* 1) based on the test conditions: 20km/h speed, flat and straight concrete road, wind speed less than 5m/s, temperature of 25 Celsius degree;
2) Range will vary depending on temperature, grade, payload and driving style.
Dimensions
| Item | Description |
| Overall dimensions (L x W x H) | 3175x1219x1727mm |
| Ground clearance | 114mm |
| Wheelbase | 2490mm |
| Front wheel tread (mm) | 860mm |
| Rear wheel tread (mm) | 970mm |
FAQ:
1. Who are we?
We are based in Guangdong, China, start from 2016,sell to Southeast Asia(30.00%),Western Europe(30.00%),South America(20.00%),Mid East(20.00%). There are total about 201-300 people in our office.
2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.What can you buy from us?
GOLF CART,ELECTRIC BUGGY,SIGHTSEEING BUS,ACCESSORIES
4. Why should you buy from us not from other suppliers?
EXCAR is a professional manufacturer on electric cart which established in 2006. Occupied an area of 25,000 square meters and produce 250-500 carts per month.
If you'r looking for good quality cart with reasonable price, We'r the right choice to you !
