Product Details
Place of Origin: China
Brand Name: Excar
Certification: CE
Model Number: D-G11
Payment & Shipping Terms
Minimum Order Quantity: 1 Unit
Price: Negotiate
Delivery Time: 20 days
Payment Terms: L/C, T/T
Supply Ability: 1000 units per month
Seats:: |
11 |
Model:: |
G11 |
Batteries:: |
Lithium Battery |
Controller::: |
USA Curties Controller |
Warranty::: |
1 Year |
Color:: |
Customized |
Seats:: |
11 |
Model:: |
G11 |
Batteries:: |
Lithium Battery |
Controller::: |
USA Curties Controller |
Warranty::: |
1 Year |
Color:: |
Customized |
Dimensions
| Item | Description |
| Overall dimensions (L x W x H) | 5300x1500x2000mm |
| Ground clearance | 150mm |
| Wheelbase | 2850mm |
| Front wheel tread (mm) | 1210mm |
| Rear wheel tread (mm) | 1200mm |
Performance
| Item | Description | |
| system | DC system | AC system |
| Passenger Capacity | 11 | 11 |
| Climbing capacity(full load) | 20% | 25% |
| Max. forward speed | 23km/h | 45km/h |
| Endurance mileage | 50-70km | 60-80km |
| Charging time | 8-10 hours | 8-10 hours |
| Max.loading weight | 510kgs | 510kgs |
| Min.turning radius | 5.1m | 5.1m |
| Max. movement after brake at speed of 20km/h | ≤4m | ≤4m |
| CONFIGURATION | |
| MOTOR: | EXCAR 72V 7.5KW(AC) |
| CONTROLLER: | EXCAR 72V 350A AC CONTROLLER |
| BATTERIES: | 72V |
| CHARGER: | 72V 30A INTELLIGENT ONBOARD CHARGER |
| CHASSIS CONFIGURATION | |
| TRANSAXLE: | HEAVY DUTY AXLE WITH DIFFERENTIAL GEAR |
| BRAKE SYSTEM: | VACUUM BOOSTER HYDRAULIC BRAKE |
| STEERING SYSTEM: | EPS(ELECTRIC POWER STEERING) SYSTEM |
| F/R SUSPENSION: | MCPHERSON INDEPENDENT SPRING SUSPENSION |
| TYRE: | 165/70R-12 TYRE |
